Moving towards the era of smart windows, "REVERSE PNLC" uses the magic of light to create a new space

The liquid crystal smartfilm realizes the different functions of the film as "transparent", "opaque" and "as a projection screen". REVERSE is an ultra-thin liquid crystal film. It is based on the achievements of PDLC's liquid crystal technology and through display-related Developed through business cooperation.

The state of the film can be changed from transparent to opaque and vice versa by switching the power supply on and off.

This innovative product is used in a wide range of applications, such as as a replacement for blinds or curtains, or as a digital signage screen; our product features a forward-facing film that switches to transparent when the power is turned on, while Reverse film switches to transparent when power is turned off





Features: Energy saving

1. It can provide higher transparency and complete privacy; achieving a total light transmittance of 93% and a fogging degree of 98%,

2. It can be processed flexibly (design flexibility). With proper electrical process design before modularization, REVERSE PNLC can be freely processed into the ideal shape you want.

3. The ultra-thin film makes it easier to fit on curved surfaces or existing glass.

4. It can be used as a projection screen. With the optical development of our PDLC, the opaque state can display high-quality, high-definition images, such as 4K

5. Extremely wide viewing angle. REVERSE PNLC has a viewing angle of up to 160 degrees in both horizontal and vertical directions

6. Can be produced in rolls, each roll shipping unit is 50 meters, width 1500mm and 1200mm

7. Produced by Japan's exclusive technology





Suitable for environments with a sense of openness, energy-saving and efficient; economical and affordable. This transparent state can be obtained without powering on, and is suitable for environments that usually require a clear state. It can be seen even if there is a power outage, because the film is transparent when the power is out, so the view is still safe.

Transparent and unaffected during power outage

Extremely high transparency

Thickness: 0.26mm

MAX size:1450mmX 50m one roll

Transparency 93%

Response speed: 0.5 sec

Power consumption: 5W/m2

Driving voltage: AC25/80V

Working temperature: -20 degrees to 90 degrees

SWOM weather resistance experiment/weather resistance test 20000 hours test passed

Viewing angle greater than 180 degrees

1. Measurement values based on JISK 7361-1 and JIS K 7136. Other measurement values are not guaranteed.

2. Measured values at normal room temperature

3. This is the response speed of the dimming film at room temperature, excluding power startup and response time.

4. At room temperature and an area of one square meter, the measured value at the optimal voltage (square wave 40Vms 60Hz) is the power consumption of the dimmable film, excluding the power consumption of the power supply, etc.

5. The SWOM (weathering test) is tested based on JIS A 5759. The adhesive and end sealant specified by the company are used, which meets the company's requirements and specifications.
